Shantui Parts SD22 Quick Drop Valve Ass'y 154-63-14001 175-63-14111
Part Name:Quick drop valve ass'y
Part Number: 154-63-14001 175-63-14111
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY | ||
| SD22 | SD22E,SD22D | SD22R,SD22S | |||
| 30 | 158-62-01400 | Yoke plate | 2 | ||
| 30 | 154-61-11621 | Bolster | 2 | 2 | |
| 31 | 23Y-62B-01600 | Hose | 1 | ||
| 31 | 23Y-62B-02100 | Hose | 1 | ||
| 31 | 158-62-01300 | Hose (L.H.) | 1 | 1 | |
| 31 | 158-62-02200 | Hose (R.H.) | 1 | 1 | |
| 31 | 23Y-65E-04000 | Hose | 2 | ||
| 32 | 07000-13035 | O-ring | 2 | 2 | 2 |
| 33 | 01010-51050 | Bolt | 4 | 4 | 4 |
| 34 | 01010-51055 | Bolt | 4 | 4 | 4 |
| 35 | 07000-13048 | O-ring | 2 | 2 | 2 |
| 36 | 07000-12055 | O-ring | 2 | 2 | 2 |
| 37 | 154-63-14001 | Quick drop valve ass'y | 2 | 2 | 2 |
| 38 | 07282-13411 | Hose clip | 2 | 2 | 2 |
| 39 | 01010-51020 | Bolt | 4 | 4 | 4 |
| 40 | 01010-50830 | Bolt | 16 | ||
| 41 | 01643-31645 | Washer | 4 | 4 | 4 |
| 42 | 01010-51615 | Bolt | 4 | 4 | 4 |
| 43 | 07000-13025 | O-ring | 4 | ||
| 44 | 07378-10600 | Dust cover | 4 | ||
| 45 | 07371-30638 | Flange | 8 | ||
| 46 | 01643-30823 | Washer | 16 | ||
| 47 | 07165-13941 | Nut | 2 | 2 | 2 |
| 48 | 07000-02120 | O-ring | 2 | 2 | 2 |
